How to Scan Docker Images in GitLab CI

Why scan in GitLab CI specifically

GitLab CI has two properties that make it a good place to enforce scanning: merge request pipelines run before code reaches the default branch, and pipeline status is a first-class signal that branch protection rules can require. Put a scan job in the same pipeline that builds the image, and every image that reaches your registry has been checked — not as a separate manual step someone can skip under deadline pressure, but as a pipeline stage that has to pass.

The approach below scans the image as a build artifact: build it with Docker-in-Docker inside the job, export it with docker save, and scan the resulting tar file. That mirrors the pattern in our general image-scanning guide and in the GitHub Actions version of this workflow, adapted to GitLab's dind service and job model.

The complete pipeline

Save this as .gitlab-ci.yml at the root of your repository. It builds the image using the Docker-in-Docker service, scans it with ScanRook, keeps the JSON report as a pipeline artifact, and fails the job on critical or high findings:

stages:
  - build
  - scan

variables:
  DOCKER_TLS_CERTDIR: "/certs"
  IMAGE_TAR: "myapp.tar"

build_image:
  stage: build
  image: docker:27
  services:
    - docker:27-dind
  script:
    - docker build -t myapp:ci .
    - docker save myapp:ci -o "$IMAGE_TAR"
  artifacts:
    paths:
      - "$IMAGE_TAR"
    expire_in: 1 hour

scan_image:
  stage: scan
  image: alpine:3.20
  needs: ["build_image"]
  cache:
    key: "scanrook-cache-$CI_COMMIT_REF_SLUG"
    paths:
      - .scanrook-cache/
  before_script:
    - apk add --no-cache curl jq bash
    - curl -fsSL https://scanrook.sh/install | sh
  script:
    - scanrook scan --file "$IMAGE_TAR" --cache-dir "$CI_PROJECT_DIR/.scanrook-cache" --mode deep --format json --out report.json
    - |
      CRITICAL=$(jq '.summary.critical // 0' report.json)
      HIGH=$(jq '.summary.high // 0' report.json)
      echo "Critical: $CRITICAL, High: $HIGH"
      if [ "$CRITICAL" -gt 0 ] || [ "$HIGH" -gt 0 ]; then
        jq '.findings[] | select(.severity == "CRITICAL" or .severity == "HIGH") | {cve, package: .package.name, version: .package.version, severity}' report.json
        echo "Failing pipeline: critical or high severity vulnerabilities found"
        exit 1
      fi
  variables:
    NVD_API_KEY: $NVD_API_KEY
  artifacts:
    when: always
    paths:
      - report.json
    expire_in: 30 days
  rules:
    - if: '$CI_PIPELINE_SOURCE == "merge_request_event"'
    - if: '$CI_COMMIT_BRANCH == $CI_DEFAULT_BRANCH'
    - if: '$CI_PIPELINE_SOURCE == "schedule"'

What each part does

• Two stages, one artifact. The build_image job builds and saves the image, passing the tar to scan_image through job artifacts. Splitting the stages means a failed scan does not force a rebuild — you can re-run just the scan job if a transient network error hits an advisory source.
• Docker-in-Docker. The docker:27-dind service gives the build job a Docker daemon to build against. This requires the GitLab Runner executor to allow privileged mode — confirm with your platform team if you are on shared runners, since some organizations disable it by default for security reasons.
• A lighter scan image. The scan job does not need Docker at all, only the exported tar, so it runs in a plain alpine image without privileged mode — smaller attack surface and faster job startup.
• GitLab-native caching. The cache: block persists the scanner's data directory between runs on the same runner, keyed by branch so merge request and default-branch pipelines do not thrash each other's cache.
• Rules, not only branches.The job runs on merge request pipelines, pushes to the default branch, and scheduled pipelines — the three triggers that, together, catch both newly introduced CVEs and advisories published after merge.
• Always-on artifacts. when: always keeps report.json downloadable from the job page even when the gate step fails, which is exactly when you want to open it.

Failing merge requests on severity

A gate that fails every merge request on day one gets a bypass rule added within a week; a gate with no bite is theater. Three changes make this workable in practice:

Start critical-only. Drop the $HIGH condition from the if check and let high-severity findings show up in the job log without blocking. Inherited base-image findings can number in the hundreds — see how to reduce CVEs in Docker images for bringing that number down before tightening the gate to include highs.

Make it a required pipeline.In GitLab, add the scan job to your branch's merge checks (Settings → Merge requests → Merge checks → Pipelines must succeed). Without that setting, a failing job is visible but does not block the merge button.

Gate on new findings on merge requests, keep audit scope on schedule. Store the report artifact from the last default-branch pipeline and diff merge request scans against it, failing only on newly introduced CVEs. Run the full, ungated scan on the scheduled pipeline so nothing silently ages out of view.

Rollout checklist: from first scan to enforced gate

The pipeline above is the easy half. Turning it into a gate people trust is a sequence, not a switch — work through these in order and the enforcement day is uneventful:

Scanning an image that already exists in the registry

Not every scan needs a fresh build. To check a base image you are evaluating or the tag currently deployed to production, pull and save it without the dind service at all:

scan_deployed_image:
  stage: scan
  image: docker:27
  script:
    - docker pull "$CI_REGISTRY_IMAGE:prod"
    - docker save "$CI_REGISTRY_IMAGE:prod" -o deployed.tar
    - curl -fsSL https://scanrook.sh/install | sh
    - scanrook scan --file deployed.tar --format json --out deployed.json
  artifacts:
    paths:
      - deployed.json
  rules:
    - if: '$CI_PIPELINE_SOURCE == "schedule"'

Running this alongside the build-time scan on the nightly schedule gives you two reports: what the next merge would ship versus what is actually running. A widening gap between them is a signal to redeploy even if nothing in the repository has changed.

Operational notes

• Store NVD_API_KEY as a masked, protected CI/CD variable in project settings, never inline in the YAML.
• Pin the docker:27 and docker:27-dind image tags to a specific patch version for reproducible builds across runners.
• For a multi-project group building several images, define the scan job once in an included template (include: project) so every repository inherits the same gate without copy-pasting YAML.
• Keep report artifacts from default-branch pipelines beyond the default expiry if your compliance program needs a scan history — GitLab's artifact retention can be extended per job.

Full configuration reference, including a variant that diffs SBOMs between pipeline runs, is in the ScanRook docs.
